UV Sheets

Scopustech holds stock of UV Sheets mainly used as panels for machineries utilized both for protecting the workers eyes as well as protecting the machines. According to the markets demand, most of these sheets are UV added and normally with light transmittance of 20% or 50%.

Specifications

We have a stock of UV-protected panels that are mainly used for panels for machines for the protection of workers’ eyes and also for panels with resistance to outdoor conditions. Depending on market requirements, most UV panels are with semi-transparent shades with light transitions of 20% and 50%.

Calculator – Parts per board

Enter dimensions according to the item evaluation chart

M
W
L

The information provided by the calculator is for estimation purposes only. Please note that there may be significant differences between the theoretical weights. For practical weight. Depending on material, manufacturer and tolerances. Each calculation should be checked by a qualified professional. To view a table of materials, click here

Materials Table

Material Grade Density (gr/cm³) Thickness (mm) FR (Flame retardant) Colors Comments Board Width (mm) Board Length (mm)
PVC Palboard 0.58-0.62 1-10 V-0 (3-10mm) White (middle black or white) Foamed cost efficient material 2030 3050
PVC PalClear 1.4 1-15 V-0 Clear, Bronze, Greyish Blue, Smoke Gray, Diffuser, White Opal For 3-6 mm possible 2050X3050 1220 2440
PVC Palight 0.55-0.7 1-10 White, Colored Foamed, for signpostings and dispalys 1220 2440
PMMA Polycasa 1.19 2-10, 12, 15, 16, 20 Transparent, White Opal, Mirror Good wether resistance & mechanical properties 2050 3050
PC Palguard 1.2 Abrasion Resistant 2050 3050
PC Palsun 1.2 1-12 Clear, Semi Transparent, Colored UV Resistant, 1=ones sided, 2= two sided 1220 2440
PC + PMMA Palshield 19 Clear Balistic Wndows, weight ~ 23 kg/sqm 1220 2440
PC Lexan F2000 1.5-8 HB (1.5-6) Clear Bronze, Opal
PC MR5E 3, 4, 5, 6, 8, 9.5 and 12 Clear Bronze With Anti Scratch 2050 3050
PC FMR5E Clear Bronze Forming with Anti Scrathc 2050 3050

Need raw material for your project?

Looking to produce a new panel for 3D Printer, Electronic or any other machinery? Uncertain about material selection for your new project? Looking for materials with International Standards? Looking for Anti-Static, UV, Scratch Resistant, Flame Retardant plastic sheets? You have reached the right place!

Materials list

How can we help your project?

Wondering which raw material to choose? Do you have a special and different development that requires consultation? The Scopostek team will be happy to be at your service.
